Keenetic Titan SE

New model

Keenetic Titan SE BE7200 Wi-Fi Mesh VDSL2/ADSL2+/Fiber Parental Control Modem VPN Router 2x2.5Gbit/s 3x1Gbit/s USB3.2 USB2.0 KN-4210

The most advanced operating system for your network

KeeneticOS makes managing your network a breeze. With a beautifully designed interface and rich functionality, you can build the most advanced networks that work for your family or business and protect against cyber threats.

Learn more
Keenetic Titan SE
Keenetic Titan SE
Keenetic Titan SE
Keenetic Titan SE
Keenetic Titan SE
Keenetic Titan SE
Keenetic Titan SE
Keenetic Titan SE
    • Get fast internet access up to 2.5 Gbps or DSL up to 300 Mbps fiber and stay online using multiple internet providers at the same time
    • Extend Wi-Fi coverage with high-power Wi-Fi and advanced Mesh Wi-Fi capabilities
    • Stay protected with cybersecurity, parental controls and separate networks for personal devices, children’s devices, smart home devices and guests
    • Enjoy smoother gaming, streaming and video calls with application-aware traffic prioritisation
    • Use as a network file server and personal cloud with a USB drive and M.2 NVMe SSD

Specifications

Key features
Model number KN-4210
CPU MT7988D 1800 MHz, triple core
RAM 1024 MB DDR4
Flash memory, Dual Image 256 MB
Wi-Fi 2.4 + 5 GHz ✔
Wi-Fi class BE7200
Wi-Fi antennas 2.4 GHz: 4 internal
5 GHz: 5 internal
Zero wait DFS: 1 internal
Wi-Fi client capacity Up to 512 in 2.4 & 5 GHz (shared)
Ethernet ports 2 × 2.5 Gbps, 3 × 1 Gbps
Link aggregation Static (ports 1 + 2)
WPS/Wi-Fi button ✔
FN button Yes, two buttons
USB ports 1 × USB 2.0, 1 × USB 3.2
M.2 slot M.2 2280 PCIe 3.0 ×1 NVMe
Mobile data connection Via a compatible USB modem
DSL connection Built-in ADSL2+/VDSL2 modem
Mesh Wi-Fi System ✔
DFS support Zero Wait DFS (ch. 52–140)
Performance
2.4 GHz Wi-Fi network 1376 Mbps (802.11be)
4T × 4R: 4SS, 40 MHz
5 GHz Wi-Fi network 5764 Mbps (802.11be)
4T × 5R: 4SS, 160 MHz
IPoE/PPPoE routing Up to 5000 Mbps in duplex
L2TP/PPTP routing Up to 2500 Mbps
WireGuard throughput Up to 900 Mbps
Reading from a USB drive Up to 270 MB/s (USB 3.2)
Reading from an NVMe SSD Up to 270 MB/s
DSL protocol support
Automatic selection of ADSL modulation ✔
G.Dmt, G.Lite, ADSL2, ADSL2+ ✔
The maximum number of PVC 8
VDSL2, 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a profiles ✔
VDSL2, 35b profile ✔
G. vector support ✔
Wireless network
Seamless roaming 802.11k/r/v ✔
MU-MIMO ✔
Airtime Fairness ✔
Beamforming ✔
OFDMA ✔
Multi-Link Operation (MLO) ✔
Preamble Puncturing ✔
Pre-configured Wi-Fi protection ✔
WEP, WPA-PSK ✔
WPA2-PSK, WPA2-Enterprise ✔
WPA3-PSK, WPA3-Enterprise, OWE ✔
Multiple Wi-Fi networks Up to 7
Access control by MAC address ✔
Wi-Fi Multimedia (WMM) ✔
Features and protocols
IPoE, PPPoE, PPTP, L2TP, 802.1x ✔
Multi-WAN ✔
Policy routing ✔
Internet connection backup ✔
Ping Check connectivity monitor ✔
PPPoE/PPTP/L2TP pass-through ✔
VLAN IEEE 802.1Q ✔
Routing table (DHCP/Manual) ✔
IntelliQoS ✔
DHCP (client/server) ✔
IPv6 Dual Stack ✔
NAT ✔
IGMP ✔
UDP to HTTP proxy ✔
UPnP ✔
Manual port forwarding ✔
SPI firewall with protection against DoS attacks ✔
PPTP (client/server) ✔
L2TP over IPsec client/server ✔
OpenVPN client/server ✔
SSTP client/server ✔
Ethernet-over-IP, IP-IP, GRE ✔
IPsec VPN (client/server) ✔
WireGuard ✔
Dynamic DNS client ✔
Direct or cloud access via KeenDNS ✔
HTTPS security for access via KeenDNS ✔
Yandex.DNS Internet filter ✔
Cloudflare DNS ✔
SafeDNS parental control ✔
AdGuard ad blocker ✔
Traffic statistics per client ✔
Bandwidth limit per client ✔
Access schedule per client or interface ✔
Guest hotspot with authentication (Captive Portal) ✔
USB applications
Support for 5G/4G/3G USB modems ✔
RAS, NDIS, CDC-Ethernet, QMI support ✔
File server and personal cloud ✔
FAT, FAT32, exFAT, NTFS, EXT2, EXT3, EXT4, HFS+ support ✔
CIFS/SMB ✔
AFP ✔
FTP, SFTP ✔
WebDAV ✔
Time Machine, File History support ✔
OPKG packages ✔
Download Station ✔
File server ✔
Media server ✔
Print server ✔
Troubleshooting and management
Cloud-based Remote Network Monitoring and Management ✔
Mobile app for Android and iOS ✔
Web Interface with the Initial Setup Wizard and HTTPS security ✔
Command Line (CLI) via TELNET/SSH ✔
An option to control from external network ✔
Backup and restore configuration ✔
Automatic OS updates ✔
System event logging ✔
Physical specifications and environment requirements
Device dimensions, w x d x h 95 mm × 250 mm × 250 mm
Device weight 1054 g
Operating temperature 0–40 °С
Operating humidity 20–95% non-condensing
Power supply voltage 100–240 V 50/60 Hz
Package contents
Device ✔
Power adapter 12 V 3.5 A
Ethernet cable ✔
Wall mount kit ✔
Telephone cable ✔
DSL splitter ✔
Quick start guide ✔
