Keenetic Titan (KN-1811)

Keenetic Titan

AX3200 Mesh Wi-Fi 6 Multi-Gigabit Router with Dual Core ARM CPU, a 5-Port Gigabit and 1-Port 2.5 Gigabit Smart Switch, USB 2.0 and USB 3.0 Ports

Continuous Fast Reliable Internet
Cutting Edge Wi-Fi Coverage
IntelliQoS Traffic Prioritization
Smooth 4K UHD Video Streaming
Cyberthreat Protected & Family Safe
Powerful Network Storage & Personal Cloud

Model number	KN-1811
CPU	MT7622B 1350 MHz, dual core
RAM	512 MB DDR3
Flash memory, Dual Image	256 MB
Wi-Fi 2.4 + 5 GHz	✔
Wi-Fi class	AX3200
Wi-Fi antennas	External
Ethernet ports	5 x 1 Gbps, 1 x 2.5 Gbps
WPS/Wi-Fi button	✔
FN button	Yes, two buttons
USB ports	1 x USB 2.0, 1 x USB 3.0
3G/4G connection	Via a compatible USB modem
Mesh Wi-Fi System	✔

Model number

KN-1811

CPU

MT7622B 1350 MHz, dual core

RAM

512 MB DDR3

Flash memory, Dual Image

256 MB

Wi-Fi 2.4 + 5 GHz

✔

Wi-Fi class

AX3200

Wi-Fi antennas

External

Ethernet ports

5 x 1 Gbps, 1 x 2.5 Gbps

WPS/Wi-Fi button

✔

FN button

Yes, two buttons

USB ports

1 x USB 2.0, 1 x USB 3.0

3G/4G connection

Via a compatible USB modem

Mesh Wi-Fi System

✔

2.4 GHz Wi-Fi network	800 Mbps (802.11n)
5 GHz Wi-Fi network	2402 Mbps (802.11ax)
IPoE/PPPoE routing	Up to 2500 Mbps
L2TP/PPTP routing	Up to 1500 Mbps
Reading from a USB drive	Up to 270 MB/s (USB 3.0)

2.4 GHz Wi-Fi network

800 Mbps (802.11n)

5 GHz Wi-Fi network

2402 Mbps (802.11ax)

IPoE/PPPoE routing

Up to 2500 Mbps

L2TP/PPTP routing

Up to 1500 Mbps

Reading from a USB drive

Up to 270 MB/s (USB 3.0)

Seamless roaming 802.11k/r/v	✔
MU-MIMO	✔
Airtime Fairness	✔
Beamforming	✔
OFDMA	✔
Pre-configured Wi-Fi protection	✔
WEP, WPA-PSK	✔
WPA2-PSK, WPA2-Enterprise	✔
WPA3-PSK, WPA3-Enterprise, OWE	✔
Multi-SSID and Guest Network	✔
Access control by MAC address	✔
Wi-Fi Multimedia (WMM)	✔

Seamless roaming 802.11k/r/v

✔

MU-MIMO

✔

Airtime Fairness

✔

Beamforming

✔

OFDMA

✔

Pre-configured Wi-Fi protection

✔

WEP, WPA-PSK

✔

WPA2-PSK, WPA2-Enterprise

✔

WPA3-PSK, WPA3-Enterprise, OWE

✔

Multi-SSID and Guest Network

✔

Access control by MAC address

✔

Wi-Fi Multimedia (WMM)

✔

IPoE, PPPoE, PPTP, L2TP, 802.1x	✔
Multi-WAN	✔
Policy routing	✔
Internet connection backup	✔
Ping Check connectivity monitor	✔
PPPoE/PPTP/L2TP pass-through	✔
VLAN IEEE 802.1Q	✔
Link aggregation	✔
Routing table (DHCP/Manual)	✔
IntelliQoS	✔
DHCP (client/server)	✔
IPv6 Dual Stack	✔
NAT	✔
IGMP	✔
UDP to HTTP proxy	✔
UPnP	✔
Manual port forwarding	✔
SPI firewall with protection against DoS attacks	✔
PPTP (client/server)	✔
L2TP over IPSec client/server	✔
OpenVPN client/server	✔
SSTP client/server	✔
Ethernet-over-IP, IP-IP, GRE	✔
IPsec VPN (client/server)	✔
WireGuard	✔
Dynamic DNS client	✔
Direct or cloud access via KeenDNS	✔
HTTPS security for access via KeenDNS	✔
Yandex.DNS Internet filter	✔
Cloudflare DNS	✔
SafeDNS parental control	✔
AdGuard ad blocker	✔
Traffic statistics per client	✔
Bandwidth limit per client	✔
Access schedule per client or interface	✔
Guest hotspot with authentication (Captive Portal)	✔

IPoE, PPPoE, PPTP, L2TP, 802.1x

✔

Multi-WAN

✔

Policy routing

✔

Internet connection backup

✔

Ping Check connectivity monitor

✔

PPPoE/PPTP/L2TP pass-through

✔

VLAN IEEE 802.1Q

✔

Link aggregation

✔

Routing table (DHCP/Manual)

✔

IntelliQoS

✔

DHCP (client/server)

✔

IPv6 Dual Stack

✔

NAT

✔

IGMP

✔

UDP to HTTP proxy

✔

UPnP

✔

Manual port forwarding

✔

SPI firewall with protection against DoS attacks

✔

PPTP (client/server)

✔

L2TP over IPSec client/server

✔

OpenVPN client/server

✔

SSTP client/server

✔

Ethernet-over-IP, IP-IP, GRE

✔

IPsec VPN (client/server)

✔

WireGuard

✔

Dynamic DNS client

✔

Direct or cloud access via KeenDNS

✔

HTTPS security for access via KeenDNS

✔

Yandex.DNS Internet filter

✔

Cloudflare DNS

✔

SafeDNS parental control

✔

AdGuard ad blocker

✔

Traffic statistics per client

✔

Bandwidth limit per client

✔

Access schedule per client or interface

✔

Guest hotspot with authentication (Captive Portal)

✔

Mobile broadband modem support	✔
RAS, NDIS, CDC-Ethernet, QMI support	✔
File server and personal cloud	✔
FAT, FAT32, exFAT, NTFS, EXT2, EXT3, EXT4, HFS+ support	✔
CIFS/SMB	✔
AFP	✔
FTP, SFTP	✔
WebDAV	✔
Time Machine, File History support	✔
Support for third-party extension packages from the Entware and Debian repositories	✔
Download Station	✔
File server	✔
Media server	✔
Print server	✔

Mobile broadband modem support

✔

RAS, NDIS, CDC-Ethernet, QMI support

✔

File server and personal cloud

✔

FAT, FAT32, exFAT, NTFS, EXT2, EXT3, EXT4, HFS+ support

✔

CIFS/SMB

✔

AFP

✔

FTP, SFTP

✔

WebDAV

✔

Time Machine, File History support

✔

Support for third-party extension packages from the Entware and Debian repositories

✔

Download Station

✔

File server

✔

Media server

✔

Print server

✔

Cloud-based Remote Network Monitoring and Management	✔
Mobile app for Android and iOS	✔
Web Interface with the Initial Setup Wizard and HTTPS security	✔
Command Line (CLI) via TELNET/SSH	✔
An option to control from external network	✔
Backup and restore configuration	✔
Automatic OS updates	✔
System event logging	✔

Cloud-based Remote Network Monitoring and Management

✔

Mobile app for Android and iOS

✔

Web Interface with the Initial Setup Wizard and HTTPS security

✔

Command Line (CLI) via TELNET/SSH

✔

An option to control from external network

✔

Backup and restore configuration

✔

Automatic OS updates

✔

System event logging

✔

Device dimensions excluding antenna, w x d x h	214 mm x 154 mm x 33 mm
Device weight	500 g
Operating temperature	0–40 °С
Operating humidity	20–95% non-condensing
Power supply voltage	100–240 V 50/60 Hz

Device dimensions excluding antenna, w x d x h

214 mm x 154 mm x 33 mm

Device weight

500 g

Operating temperature

0–40 °С

Operating humidity

20–95% non-condensing

Power supply voltage

100–240 V 50/60 Hz

Device	✔
Power adapter	12 V 2.5 A
Ethernet cable	✔
Quick start guide	✔

Device

✔

Power adapter

12 V 2.5 A

Ethernet cable

✔

Quick start guide

✔

Keenetic Titan

Specifications
